Specifications:

• Mil spec FR4 circuit board
• Regulated power supply
• Constant LED current and brightness regardless of battery voltage (won’t dim with your beat)
• 20 bright surface mount LEDs
• Wide operating voltage range for vehicles with modified electrical systems
• 3 speed fan drive system (PWM)

• Remote wired sensor with 18 feet of cable
• Operating voltage range for power supply: 8vdc-22vdc
• Display Range: 30 - 220F/ C
• Fan Set Point Range: 40 - 200 F/ C
• Accuracy: /- 5 Degrees (due to display type)
• Maximum Fan Load: 5 Amps DC
• 2.75" x 2.75" x 0.6" depth
